| parameter | symbol | min | max | units | note |
| ld reserve voltage | vr | 2 | v | ||
| ld forward current | if | 120 | ma | ||
| mpd reverse voltage | imf | 20 | v | ||
| mpd forward current | im | 10 | ma | ||
| storage temperature | - | -40 | 85 | °c | |
| operating temperature | - | 0 | 85 | °c | |
| soldering temperature | tsold | 260 | °c | <10s on leads |
| parameter | symbol | test condition | min | typ | max | unit |
| optical wavelength | l | cw, iop=ith 20ma | 1260 | 1270 | 1280 | nm |
| threshold current |
ith | cw | - | 5 | 15 | ma |
| tc=85℃ | - | - | 40 | ma | ||
| operating voltage | vf | cw, iop=ith 20ma | - | 1.2 | 1.6 | v |
| optical output power | pf | cw, iop=ith 20ma | 0.6 | - | 1.6 | mw |
| slope efficiency | se | cw, ith~ith 20ma | 0.03 | - | 0.08 | mw/ma |
| rise time (20~80%) | tr | ib=ith, 20%~80% | - | 35 | - | ps |
| fall time (20~80%) | tf | ib=ith, 20%~80% | - | 45 | - | ps |
| pd monitor current | ipd | cw, iop=ith 20ma | 0.1 | - | 1.0 | ma |
| pd dark current | id | vr=5v | - | - | 100 | na |
| tracking error | te | cw, pf=ith 20ma,0℃ and85℃ | -1.5 | - | 1.5 | db |
| parameter | symbol | test condition | min | typ | max | unit |
| operating wavelength | l | - | 1320 | 1330 | 1340 | nm |
| power supply | vcc | - | 3.0 | - | 3.6 | v |
| tia supply current | icc | vcc=3.3v | - | - | 62 | ma |
| small-signal bandwidth | bw | - | 7.0 | - | - | ghz |
| rise / fall time | tr/tf | 20 % ~ 80 % | - | - | 50 | ps |
| sensitivity | s | 10gbps,er=7db, prbs2^31-1, ber=10^-12 | - | - | -16 | dbm |
| overload | ol | 0 | - | - | dbm |
