parameter | symbol | min | max | units | note |
storage temperature | tstg | -40 | 100 | °c | |
operating temperature | tc | -40 | 85 | ||
soldering temperature | tsold | 260 | °c | <10s on leads |
parameter | symbol | test condition | min | typ | max | unit |
power supply | vcc | 3.0 | 3.3 | 3.6 | v | |
tia supply current | icc | vcc=3.3v | - | 27 | 40 | ma |
wavelength | λ | cw | 1260 | 1620 | nm | |
sensitivity | s | λ=1310nm,@10.31gbps, prbs31, er=6db, ber=1e-12 |
- | - | -15 | dbm |
saturation power | psat | λ=1310nm,@10.31gbps, prbs31, er=6db, ber=1e-12 |
-3 | - | - | dbm |
small-signal bandwidth | bw | pin=-18dbm,-3db point | 7 | - | - | mhz |
output impedance |
rout | - | 40 | 50 | 60 | ω |
optical return loss | orl | λ=1310nm and 1550nm | 12 | db |
