1270nm~1610nm round free space optical isolator for 10g 25g tosa bosa
siny optic-com co.,ltd.was established in 2008 in shenzhen china, is a professional optical communication company,specializing in providing optical components to optical device and optical transceiver manufacturers.siny has focused on the r&d,production,sales of fiber optical isolator,fiber optic receptacle,receptacle isolator, various of receptacle,tosa,bosa,rosa,to and other passive components,which are widely used in optical communication products,such as optical device, optical transceiver, optical module,gas sensors,lasers and detectors.
free space optical isolator application
2.5g-400g optical module
gpon/epon olt module
tunable laser module
aeronautics and astronautics
far ir laser
sensor
gas detector
sinlge stage free space optical isolator specifications
| parameters |
specification |
units |
| center wavelength |
1270~1610 |
nm |
| operating wavelength |
±20 |
nm |
| clear aperture |
φ0.4-3.0 |
mm |
| insertion loss(λc,23℃) |
≤0.3 |
db |
| isolation(λc,23℃) |
≥35 |
db |
| operating temperature |
-40 to 85 |
℃ |
| storage temperature |
-40 to 85 |
℃ |
| max. optical power |
300 |
mw |
dual stage free space optical isolator specifications
| parameters |
specification |
units |
| center wavelength |
1270~1610 |
nm |
| operating wavelength |
±20 |
nm |
| clear aperture |
φ0.4-3.0 |
mm |
| insertion loss(λc,23℃) |
≤0.5 |
db |
| isolation(λc,23℃) |
≥55 |
db |
| operating temperature |
-40 to 85 |
℃ |
| storage temperature |
-40 to 85 |
℃ |
| max. optical power |
300 |
mw |
