dual stage smt free space optical isolator

free space optical isolator is a passive magneto-optic device which transmits light in a certain direction while blocking light in the opposite direction. faraday isolators are based on faraday rotators and fraday effect and constitute the technologically most important type of optical isoloators. optical isolator is widely used in applications that to avoid unwanted light feedback.

dual stage free space optical isolator feature
high isolation
low insertion loss
high reliability
rohs complaint
compact size
optimized for different wavelengths

dual stage free space optical isolator application
transmitter optical sub assembly（tosa）
bi-directional optical sub assembly(bosa)
gpon/epon olt module
optical transmitters and transceivers
optical sensor
laser diode packaging
tunable laser module

dual stage free space optical isolator specification

product	center wavelength (λc),nm	isolation (λc,23℃),db	insertion loss (λc,23℃),db	clear aperture (mm)
single stage smt free space optical isolator	1270-1610	＞35	＜0.3	φ0.4-1.0
dual stage smt free space optical isolator	1270-1610	＞50	＜0.6	φ0.4-1.0

siny factory

siny optical isolator workshop
