| parameter | specification | ||||||
| center wavelength (nm) | 1310/1550/1590 | ||||||
| standard/mini size | standard size | mini size | |||||
| single/dual stage | single (w/o pmd) |
single (with pmd) |
dual | single | dual | ||
| isolation (db) | (at λc) 1 | min | 32 | 32 | 46 | 30 | 46 |
| (at λc±15nm) 2 | min | 22 | 22 | 40 | 20 | 36 | |
| insertion loss (db) | (at λc) 1 | typ | 0.45 | 0.45 | 0.5 | 0.4 | 0.6 |
| (at λc±15nm) 2 | max | 0.6 | 0.6 | 0.7 | 0.6 | 0.8 | |
| return loss (input/output) (db) | min | 60/55 | 60/55 | 60/55 | 55/55 | 55/55 | |
| pdl (db) | max | 0.05 | 0.05 | 0.05 | 0.1 | 0.1 | |
| pmd (ps) | max | 0.25 | 0.05 | 0.05 | 0.25 | 0.05 | |
| operating temperature(°c) | -30~ 70 | ||||||
| storage temperature (°c) | -40~ 85 | ||||||
| maximum power handling (mw) | 500 | ||||||
| package dimension (l*∅) (mm) | 30*5.5 | 35*5.5 | 26*3.8 | ||||
