iwdm
isolator/wdm hybrid component (1550nm/980nm)

iwdm integrates the functionalities of a polarization insensitive optical isolator and a 1550/980nm wdm.this product offers integrated solutions to edfa application by combining more fuctions into a very compact package,it can help to save fiber coiling space,reduce splicing and fiber coiling works while raising up the system reliability and increasing module design efficiency.

iwdm features
miniaturized size
high isolation
ultra low pdl&pmd
highly stable&reliablility
epoxy-free optical path
rohs&reach compliant

iwdm application
edfa
mini edfa
xfp edfa
ultra mini edfa

iwdm specification

parameters		min	typ	max	unit
operating temperature		-5		70	℃
storage temperature		-40		85	℃
operating relative humidity		5		95	%
storage relative humidity		5		95	%
signal wavelength		1528~1565（c band)			nm
pump wavelength		965-995			nm
signal insertion loss				1.0	db
pump insertion loss				0.5	db
isolator isolation	single stage	20			db
isolator isolation	dual stage	35			db
wdm pass isolation		25			db
wdm reflect isolation		15			db
pdl				0.2	db
return loss		50			db
directivity		50			db
pmd	single stage			0.25	ps
pmd	dual stage			0.05	ps
optical power				500	mw
fiber type	common&pump	by pn
fiber type	signal	zbl fiber
fiber length		1.0 or 1.5 or customized			m
fiber bending radius		≥7.5			mm
fiber jacket		by pn
package dimension		ф2.8 x l25 (glass tube) ф3.0x l28 ( metal holder ) customize			mm
connector type(all ports)		0=none,1=fc/upc,2=fc/apc 3=sc/upc,4=sc/apc 5=lc/upc,6=lc/apc
fiber color	common	black
	signal	natural
	pump	natural

above specifications are for device without connectors.
for devices with connectors,il will be 0.3db higher,rl will be 5db lower.

mechanical dimensions
